# How does ultra-wideband work?

## Traveling at the speed of light

In the previous post, we saw that we can obtain our position by measuring the distances to the anchors. So how do we do this? We use radio waves. The idea is to send radio waves from one module to another and measure the time of flight (TOF), or in other words, how long it takes. Because radio waves travel at the speed of light (c = 299792458 m/s) we can simply divide the time of flight by this speed to get the distance.

However, perhaps you've noticed that the radio waves travel fast. Very fast! In a single nanosecond, which is a billionth of a second, a wave has traveled almost 30 cm. So if we want to perform centimeter accurate ranging, we have to be able to measure the timing very very accurately! So now the question is, how can we do this? How can we even measure the timing of.. a wave?

## It's all about the bandwidth

In physics, there is something called the Heisenberg's uncertainty principle. The principle states that it is impossible to know both the frequency and the timing of a signal. Consider for example a sinusoid; a signal with a well-known frequency but a very ill-determined timing: the signal has no beginning or end. However, if we combine multiple sinusoidal signals with a slightly different frequency, we can create a 'pulse' with more defined timing, i.e., the peak of the pulse. This is seen in the following figure from wikipedia that sequentially adds sinusoids to a signal to get a sharper pulse:

fig. 1

The range of frequencies that are used for this signal is called the bandwidth Δf. Using Heisenberg's uncertainty principle we can roughly determine the width Δt of the pulse, given a certain bandwidth Δf*:

ΔfΔt ≥ 1/4π

From this simple formula we can see that if we want a narrow pulse, which is necessary for accurate timing, we need to use a large bandwidth. For example, using the bandwidth Δf = 20 MHz available for wifi systems we obtain a pulse-width larger than Δt ≥ 4ns. Using the speed of light this relates to a pulse of 1.2 m 'long' which is too much for accurate ranging. Firstly, because it is hard to accurately determine the peak of such a wide pulse, and secondly because of reflections. Reflections come from the signals bouncing onto objects (walls, ceilings, closets, desks, etc..) within the surrounding environment. These reflections are also captured by the receiver and may overlap with the line-of-sight pulse which makes it very hard to measure the true peak of the pulse. With pulses of 4 ns wide, any object within 1.2 m of the receiver or the transmitter will cause an overlapping pulse. Because of this, ranging from wifi using time-of-flight is not suitable for indoor applications.

The ultra-wideband signals that are used in Pozyx have a bandwidth of 500 MHz resulting in pulses of 0.16 ns wide! This timing resolution is so fine that at the receiver, we are able to distinguish several reflections of the signal. Hence, it remains possible to do accurate ranging even in places with a lot of reflectors, such as indoor environments.

fig. 2

## Where to put all this bandwidth?

So we need a lot of bandwidth. Unfortunately, everybody wants it: in wireless communication systems, more bandwidth means faster downloads. However, if everybody would transmit signals on the same frequencies, all the signals would interfere and nobody would be able to receive anything meaningful. Because of this, the use of the frequency spectrum is highly regulated.

So how is it possible that UWB gets 500 MHz of precious bandwidth and most other systems have to satisfy with a lot less? Well, the UWB systems are only allowed to transmit at very low power (the power spectrum density must be below -41.3 dBm/MHz). This very strict power constraint means that a single pulse is not able to reach far: at the receiver, the pulse will likely be below the noise level. In order to solve this issue, a train of pulses is sent by the transmitter (typically 128 of 1024) to represent a single bit of information. At the receiver, the received pulses are accumulated and with enough pulses, the power of the 'accumulated pulse' will rise above the noise level and reception is possible. Hooray!

The IEEE 802.15.4 standard for Low-Rate Wireless Personal Area Networks has defined a number of UWB channels of at least 500MHz wide. Depending on the country you're in, some of these channels are either allowed or not. In general, the lower band channels (1 to 4) can be used in most countries under some limitations on update rate (using mitigation techniques). Channel 5 is accepted in most parts of the world without any limitations, with the notable exception of Japan. Purely from physics, the lower the channel center frequency, the better the range.

 Channel Center frequency (MHz) Band (MHz) Bandwidth (MHz) Remarks 1 3494.4 3244.8 – 3744 499.2 2 3993.6 3774 – 4243.2 499.2 Preferred channel for long-range 3 4492.8 4243.2 – 4742.4 499.2 4 3993.6 3328 – 4659.2 1331.2 5 6489.6 6240 – 6739.2 499.2 Accepted without restrictions in most parts of the world 6 6988.8 6739.2 – 7238.4 499.2 Not supported at the moment 7 6489.6 5980.3 – 6998.9 1081.6

Table 1. UWB channels defined by the IEEE 802.15.4 standard.
